| Parameter Category | VSG-500A (Manual) | VSG-1000B (Semi-Auto) | VSG-1500C (Full-Auto) | VSG-2000D (Heavy-Duty) |
|---|---|---|---|---|
| Processing Capacity | Max seam length: 500mm Seam width: 2-20mm |
Max seam length: 1000mm Seam width: 2-30mm |
Max seam length: 1500mm Seam width: 2-40mm |
Max seam length: 2000mm Seam width: 5-50mm |
| Grinding System | Speed: 1000-2000rpm (fixed) Pressure: Manual (0.5-3bar) |
Speed: 800-2500rpm (adjustable) Pressure: Pneumatic (0.5-4bar) |
Speed: 500-3000rpm (stepless) Pressure: PLC (0.5-4.5bar) |
Speed: 500-2800rpm (stepless) Pressure: Hydraulic (1-5bar) |
| Workpiece Clamping | Manual clamp Max thickness: 50mm |
Pneumatic clamp Max thickness: 80mm |
Electric clamp with sensor Max thickness: 100mm |
Hydraulic clamp with anti-slip Max thickness: 150mm |
| Control System | Mechanical knob | 5-inch LCD | 7-inch touchscreen + PLC | 10-inch touchscreen + IoT |
| Power Supply | 220V/50Hz; 1.5kW | 380V/50Hz; 3kW | 380V/50Hz; 4.5kW | 380V/50Hz; 7.5kW |
| Certifications | CE | CE, ISO 9001 | CE, ISO 9001 | CE, ISO 9001 |
